Description & Specifications
SUPER offers jacketed reactors in all glass construction , jacketed reactors with glass lined steel, and jacketed reactors in stainless steel. In all the cases the overhead equipment such as condensers, reflux dividers, receivers and piping components are borosilicate glass. REACTOR operating pressure 0.5kg/cm² or full vacuum temperature 200°C - 20 litre spherical flask with one DN 80 nozzle at to centre for drive assembly, DN 80 nozzle on top at 45°, 2 Nos. DN 40 nozzles. HEATING - Electrical heating mantle 3kw AGITATOR DRIVE - 0.37kw, 1440 rpm Flame-proof induction motor - Helical gear box with chuck - Frequency Variator for speed control SHAFT SEALING - Dry running bellow type single mechanical seal AGITATOR TYPE - Borosilicate glass shaft with PTFE blades BOTTOM OUTLET VALVE - Borosilicate glass - Flush type SPARGER - DN 25 Borosilicate glass OVERHEAD CONDENSER - Borosilicate glass coil type 0.35 m² SUPPORTING FRAME WORK - Supporting frame work is of 25 NB stainless steel pipes and connectors. - Mild steel powder coated trolley for movement. OPTIONAL - cylindrical reactor - cylindrical jacketed reactor - Available in 10 lit, 50 lit, 100 lit, 200 lit capacity |
