Equipment Details


Reaction Vessels

>> Chemical & Bulk Drugs
Model:

NSI Equipments Private Limited
Uttar Pradesh, Uttar Pradesh - India
>> Equipment Manufacturer

Description & Specifications


Function
Reaction Vessels are used in carrying out a wide variety of chemical reactions including condensation, polymerization, esterification etherifciation, hydrolysis, hydration, reduction, oxidation, hydrogenation etc. at pressures (Up to 30 Kg. / cm) and at temperatures ranging -20C to +250C. Reaction needing simultaneous fractional distillation and azeotropic distillation can also be conducted very efficiently using these chemical reaction vessels.

Material of Constructions
Various materials of construction, such as MS, SS304, SS 316, SS 316L, Rubber Lined etc, can be offered as per requirement.

Technical Data

Nominal Capacity (Lts.)Vessel Dimension Dia, (mm) x Straight Height (mm)Motor H.PShaft Diameter (mm)Exchange Surface Area (sq. meters)Standard Design Pressure
JacketHalf - Tube
250600 x 9002.0301.70.90
Inside -3 bar or vacuum

Jacket - 3 bar





500800 x 10003.0502.71.53
10001000 x 14005.0504.42.75
20001200 x 18007.5606.84.33
25001300 x 190010.0707.84.96
30001400 x 200010.0758.86.2
